Description

Electric bicycle conversion kit bafang bbs01 mid drive motor ebike conversion kit

euwarehosue(001)

We have in stock in Spain and Belgium Warehouse. if you need shipping from Spain or Belgium, please contact us in advance.

Product list

c18(001)

Product Paramenters

Motor	36v 350w
Bracket bottom length	68mm
No Load Speed(RPM)	83-87
Load Speed(RPM)	78-83
MAX Torque	80 N.m
Efficiency (%)	≥ 80 %
Certificate	ROHS,CE
Operating Temperature	-20-45℃
Gross weight(kg)	8
Package size	250-750W: 322525cm
Warranty	1 year for the motor
IP	IP65
Noise grade	<55
Operation Temperature	-20-45℃
Reduction Ratio	1 : 21.9

Ebike conversion kit

Details Images

The mid motor is the motor placed in the middle of the frame. The advantage of the mid-mounted motor is that it can maintain the front and rear weight balance of the vehicle as much as possible, and will not affect the action of the shock absorber. The road impact on the motor is also smaller, the integration is high, and the motor shape is more concise; on the ground with poor road conditions It’s better than the hub motor in terms of handling, stability, and passability. Under the same battery capacity, the unique power transmission structure and drive mode of the mid-mounted motor make its power and endurance better than the hub motor. The motor performs better.

The steadily rising procurement demand and product supply have linked the development of suppliers and customers, and promoted the development of upstream and downstream enterprise chains; energy-saving and emission-reduction products are sold globally, and actively assume their own social responsibilities for creating a green ecological environment and contributing to an ecological planet Make a contribution. Hangzhou Indigo uses practical actions to fulfill its social responsibilities and promote the harmonious and stable development of the enterprise and society.

Integrate social responsibility into enterprise development, and create more social value while creating enterprise value.
